Hydraulic Punching Press

Name: Hydraulic Punching Press
Brand: ACHIEVE HYDRAULICS & PNEUMATICS PRIVATE LIMITED
Price: 600000.0 INR
Availability: InStock

Price 600000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Hydraulic Punching Press Specification

Nominal Force
63 Ton

Power Source
Hydraulic

Condition
New

Dimension (L*W*H)
1600 mm x 1100 mm x 2100 mm

Power(W)
5.5 kW

Voltage
380 V / 50 Hz

Motor
AC Motor

PLC System
Optional

Solenoid Valve
Available

Pre-Fill Valve
Yes

Proportional Valve
Yes

Pressure Gauge
Available

Max Opening Distance
350 mm

Working Table Size
600 mm x 400 mm

Application
Suitable for Metal Sheet Punching

Operation
Semi-Automatic

Main Cylinder Diameter
160 mm

Control Type
Button/Foot Pedal

Weight
1900 kg

Noise Level
75 dB

Oil Tank Capacity
220 Liters

Hydraulic Fluid
ISO VG46 or Equivalent

Safety Features
Two-Hand Control, Emergency Stop Switch

Cycle Time
6-10 s/cycle

Work Table Height
750 mm

Frame Type
H-Frame (Welded Steel Structure)

Maximum Stroke Length
180 mm

About Hydraulic Punching Press

Get supreme strength and sublime efficiency with our Hydraulic Punching Press featuring a majestic H-frame (welded steel structure) for unmatched stability. This fresh semi-automatic machine boasts a maximum stroke length of 180 mm and a versatile work table at 750 mm height, designed for precision metal sheet punching. With an ISO VG46 hydraulic system, 63-ton nominal force, and advanced safety controls, it ensures both power and protection. Order now to experience remarkable performance, minimal cycle times (6-10 s), and sheer reliability in every operation.

Versatile Application Across Metalworking

The Hydraulic Punching Press offers a supreme surface finish for various metal sheet applications, making it an ideal choice for manufacturing plants, workshops, and fabrication sites. It is widely used as a powerful solution for punching, shaping, and forming metals with accuracy, serving sectors like automotive, construction, and heavy machinery. The robust welded H-frame ensures stability and long-term durability, making it essential where precision punching of metal sheets is required.

Prompt Sample Availability and Global Shipping

Majestic in both capability and service, our Hydraulic Punching Press samples are readily available for inspection and testing. Efficient transportation and rapid delivery are our priorities, ensuring your press is securely shipped to main export markets worldwide. With streamlined logistics, order fulfillment and shipping times are designed for minimal waiting, so you get your machinery promptly-ready for instant operation in your facility.

FAQ's of Hydraulic Punching Press:

Q: How does the semi-automatic operation process of the Hydraulic Punching Press work?

A: The semi-automatic operation allows users to control the punching process through either a button or foot pedal, providing convenience and precision. Safety features like the two-hand control and emergency stop enhance operator protection during each cycle.

Q: What applications is this Hydraulic Punching Press suitable for?

A: This press is suitable for metal sheet punching in industries such as automotive, construction, fabrication, and heavy machinery manufacturing, thanks to its high nominal force and robust frame.

Q: Where can the Hydraulic Punching Press be used most effectively?

A: It is most effective in production plants, workshops, and industrial facilities where precise, repetitive metal punching is required on a variety of sheet materials.

Q: When can I expect delivery of the Hydraulic Punching Press after placing an order?

A: Once ordered, your Hydraulic Punching Press is securely shipped, with delivery timelines depending on your location and transportation options, ensuring prompt arrival for immediate setup.

Q: What are the benefits of the integrated safety features in this punching press?

A: The safety features, including two-hand controls and an emergency stop switch, greatly minimize risk and enhance operator safety, ensuring compliant and secure usage during high-force operations.
